After a lot anticipation, NVIDIA lastly launched its new graphics card, the GeForce RTX 4080, on 16 November 2022. The all-new RTX 4080 structure is considerably quicker than the earlier NVIDIA Ampere. On the opposite hand, NVIDIA launched its RTX 3080 Ti in June 2021, which is about one and a half years sooner than RTX 4080. This information goes to cowl the Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti.
The two graphic playing cards are sensible of their efficiency. But to seek out the prevalence between these two, we are going to take a look at the specs and variations, gaming efficiency, and different options that might make it simpler to distinguish. Also, be certain that to take a look at our comparability between RTX 4080 vs RTX 3080.
Key Takeaways
The Ada Lovelace structure and AD-103 chip of RTX 4080 are the most recent and higher than Ampere structure and GA-102 chip RTX 3080.
The RTX 4080 has 4 GB extra RAM than the RTX 3080 Ti and likewise better reminiscence velocity and bandwidth.
Both the bottom and enhance clock frequencies of RTX 4080 are better than these of RTX 3080 Ti making 4080 carry out operations extra rapidly and effectively.
The gaming efficiency of the RTX 4080 is about 35-40% extra pleasing than that of the RTX 3080 Ti making it a more sensible choice for players.
NVIDIA RTX 4080 Details
The RTX 4080 GPU was previously going to come back in two configurations:
16 GB Memory variant with 9728 CUDA cores and AD103 chip.
12 GB Memory variant with fewer CUDA cores and AD104 chip.
The two variations of the RTX 4080 had been more likely to carry out so otherwise that describing each of them because the RTX 4080 was fairly incoherent. After a lot criticism from individuals, NVIDIA publicized to not launch the 12 GB mannequin. So, presently, it’s just one RTX 4080 with the next specs.
GPU Specs
NVIDIA Architecture: Ada Lovelace
Chip: AD – 103
NVIDIA CUDA® Cores: 9728
CUDA Capability: 8.9
Tensor cores: 304
Ray Tracing cores: 76
ROPs: 112
Number of Transistors: 45.9 billion
Base clock: 2.21 GHz
Boost clock: 2.51 GHz
Die Size: 378.6 mm²
NVIDIA DLSS: 3
Card Dimensions:
Length: 304 mm
Width: 137 mm
Slots: 3-Slot (61mm)
Maximum GPU Temperature: 90 °C
Graphics Card Power: 320 W
Required System Power: 750 W
Level 1 Cache: 9.5 MB
Level 2 Cache: 64 MB
NVIDIA Encoder (NVENC): 2x Eighth Generation
NVIDIA Decoder (NVDEC): fifth Generation
Supplementary Power Connectors:
3 x PCIe 8-pin cables (adapter within the field) or
450 W or better PCIe Gen 5 cable
Memory Specifications
Standard Memory Config: 16 GB GDDR6X
Memory Speed: 22.4 GB/s
Memory Interface Width: 256-bit
Bandwidth: 912 GB/s
Supported Display
Maximum Resolution & Refresh Rate: 4K at 240Hz or 8K at 60Hz with DSC, HDR
Standard Display Connectors: HDMI, 3x DisplayPort
Multi-Monitor: as much as 4
HDCP: 2.3
NVIDIA RTX 3080 Ti Details
The following specs apply to the Nvidia RTX 3080 Ti.
GPU Specs
NVIDIA Architecture: Ampere
Chip: GA-102
NVIDIA CUDA® Cores: 10240
CUDA functionality: 8.6
Tensor cores: 320
RT cores: 80
ROPs: 112
Number of Transistors: 28.3 billion
Base clock: 1.37 GHz
Boost clock: 1.67 GHz
Die Size: 628.4 mm²
Card Dimensions:
Length: 285 mm
Width: 112 mm
Slots: 2
Maximum GPU Temperature: 93 °C
Graphics Card Power: 350 W
Required System Power: 750 W
Level 1 Cache: 10 MB
Level 2 Cache: 6 MB
NVIDIA Encoder (NVENC): seventh Generation
NVIDIA Decoder (NVDEC): fifth Generation
Supplementary Power Connector: 2 x PCIe 8-pin cables (adapter to 1 x 12 pin included)
Memory Specifications
Standard Memory Config: 12 GB GDDR6X
Memory Speed: 19 GB/s
Memory Interface Width: 384-bit
Bandwidth: 717 GB/s
Supported Display
Maximum Resolution: 7680 x 4320
Standard Display Connectors: HDMI, 3x DisplayPort
Multi-Monitor: as much as 4
HDCP: 2.3
RTX 4080 Vs. RTX 3080 Ti
Technical Differences
FeatureNVIDIA RTX 4080NVIDIA RTX 3080 Ti
CoresCUDA® Cores: 9728Tensor cores: 304RT cores: 76CUDA® Cores: 10240Tensor cores: 320RT cores: 80
Clock velocityBase clock: 2.21 GHzBoost clock: 2.51 GHzBase clock: 1.37 GHzBoost clock: 1.67 GHz
TemperatureMax Temperature: 90 °CMax Temperature: 93 °C
TDPGraphics Card Power: 320 WRequired System Power: 750 WGraphics Card Power: 350 WRequired System Power: 750 W
Transistors45.9 billion28.3 billion
Die Size378.6 mm²628.4 mm²
Memory 16 GB GDDR6XInterface Width: 256-bit12 GB GDDR6XInterface Width: 384-bit
Speed and BandwidthMemory Speed: 22.4 GB/sBandwidth: 912 GB/sMemory Speed: 19 GB/sBandwidth: 717 GB/s
Architecture
The RTX 3080 Ti got here with NVIDIA’s “Ampere” structure, whereas the RTX 4080 has the brand new “Ada Lovelace” structure.
The Ampere structure was designed on the Volta structure of NVIDIA in May 2020. It was supposed for high-performance computation and synthetic intelligence. It is the primary design to utilize the Tensor Core expertise of NVIDIA. The NVIDIA Ampere structure presents unparalleled efficiency on all scales.
The Ada Lovelace of NVIDIA was launched in September 2022. This newest structure is known as after “Ada Lovelace” (who’s considered the primary laptop programmer). This structure is developed to ship ground-breaking efficiency for AI-based cognitive graphics and ray tracing. It offers a considerably improved foundation of GPU efficiency and signifies the ray tracing and neural graphics inflection level.
Chip Design
The Nvidia RTX 4080 is developed on an AD-103 chip, whereas the RTX 3080 Ti is predicated on the GA-102 chip.
The AD-103 makes use of the most recent Ada Lovelace structure of NVIDIA. It is manufactured at TSMC using a 4 nm fabrication course of. This chip has 336 tensor cores, 112 ROPs, 336 texture mapping items, and 10752 shading items. It has 45.9 billion transistors and a die dimension of 379 mm². This chip can assist DirectX 12 Ultimate.
While the GA-102 has an Ampere structure of NVIDIA, it’s manufactured by Samsung, using an 8 nm fabrication course of. The chip additionally has 336 tensor cores, 112 ROPs, 336 texture mapping items, and 10752 shading items. It has 28.3 billion transistors and a die dimension of 628 mm². The GA-102 can also assist DirectX 12 Ultimate.
NVENC Generation
NVENC stands for NVIDIA Encoder. Both graphic playing cards have totally different encoding applied sciences. The RTX 3080 Ti has an encoder of the seventh era, whereas the RTX 4080 has two Eighth-generation NVIDIA Encoders.
The Eighth era is the latest and technically extra refined, whereas the seventh era is older and fewer developed. If you need the most effective video encoding expertise obtainable, the Eighth era is the superior choice as a result of it delivers greater efficiency and high quality than the seventh era.
Also Read: RTX 4080 Vs RTX 3090
Now it’s time to maneuver on to gaming benchmarks of two graphic playing cards.
Gaming Benchmarks
To obtain higher outcomes for Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti, right here, we’ve lined the benchmarks of a complete of 21 video games divided into three collection. In the video games’ first and third collection, the decision of gameplay was 4K (2160p). While within the second collection, the video games’ decision was 1440p. The video games of every collection had been performed on totally different PC, and sources of benchmarks are additionally totally different for every collection.
First Series – 4K
The video games of the primary collection embody Assassin’s Creed Valhalla, Cyberpunk 2077, God of War, Horizon Zero Dawn, Red Dead Redemption 2, and Watch Dogs Legion. All of those video games require quite a lot of system work (extremely demanding). We compiled the benchmarks for these video games from Mike.
Test PC Specs
The system used within the gameplay of the primary collection had the next specs;
CPU: AMD RYZEN 9 5950X
Motherboard: MSI MAG B550 TOMAHAWK
RAM: 2x16GB DDR4 3600MHz G.Skill
SSD: Samsung 1TB 980 Pro PCIe 4.0 x4 M.2
Liquid Cooler: Lian-Li Galahad 360mm UNI FAN SL Edition
PSU: Cooler Master V850 SFX Gold Full Modular
PC Case: Lian Li O11 Dynamic XL
Assassin’s Creed Valhalla
Frame charges, GPU Temperature & load in Assassin’s Creed Valhalla
The high-end GPU demanding Assassin’s Creed Valhalla is likely one of the finest video games to check the efficiency of graphic playing cards.
In the gameplay of Assassin’s Creed Valhalla, the RTX 4080 turned over a most variety of frames per second of as much as 188 FPS, whereas RTX 3080 Ti gave 147 FPS at its most. And the minimal FPS produced by RTX 4080 and RTX 3080 Ti had been 51 and 21, respectively.On common, the RTX 4080 handed over 94 FPS, whereas the RTX 3080 Ti may ship a imply of solely 62 FPS through the gameplay. If you see the distinction, the RTX 4080 has delivered 50% extra FPS in comparison with the RTX 3080 Ti. A gamer at all times wants greater FPS, and between these two GPUs, RTX 4080 is delivering the most effective.
The time taken by the RTX 3080 Ti to finish one body was 17.7 milliseconds. While the RTX 4080 had a body time of solely 10.6 ms. The decrease body time is at all times good for gaming.
The temperature of RTX 4080 was 76 °C whereas the RTX 3080 Ti was working at an elevated temperature of 80 °C.
In the gameplay, the load on RTX 4080 was as much as 95%, whereas the RTX 3080 Ti had 97% stress on it. A 2% better stress was utilized to the RTX 3080 Ti than to the RTX 4080.
Cyberpunk 2077
Frame charges, GPU Temperature & GPU load in Cyberpunk 2077
The RTX 4080 produced a most of 100 frames per second throughout gaming in Cyberpunk 2077, in comparison with the RTX 3080 Ti’s most of 78. And the minimal FPS achieved by the RTX 4080 and RTX 3080 Ti had been 21 and 36, respectively.
During gameplay, the RTX 4080 delivered 74 FPS on common, whereas the RTX 3080 Ti may solely muster 54 FPS on common. As you’ll be able to see, the RTX 4080 produced 35-40% extra FPS than the RTX 3080 Ti.
The RTX 3080 Ti’s body time was 15.3 milliseconds, whereas the RTX 4080’s body time was merely 13.5 milliseconds. So, the RTX 4080 was finishing every body with an effectivity of about 1.8 ms over the RTX 3080 Ti.
The RTX 4080 had a temperature of 72 °C, whereas the RTX 3080 Ti had an working temperature of 75 °C. Thus, the RTX 4080 was 3 °C cooler than the RTX 3080 Ti.
During gameplay, the RTX 4080 was below as much as 82% of its whole load capability. At the identical time, the RTX 3080 Ti was below 98% rigidity. Here is a notable distinction in GPU load (82%) on RTX 4080 in Cyberpunk 2077 in comparison with the 95% load in Assassin’s Creed Valhalla. The RTX 4080 was coping with extremely demanding Cyberpunk 2077 as solely 82% of its whole load capability.
God of War
Frame charges, GPU Temperature & load in God of War
While enjoying God of War, in distinction to the RTX 3080 Ti’s most body price of 118, the RTX 4080 may output a most of 255 frames per second. Additionally, the RTX 4080 and RTX 3080 Ti managed to succeed in the minimal FPS of 41 and 38, respectively. The greater restrict of FPS was reached by the RTX 4080. And the decrease restrict was acquired by the RTX 3080 Ti.
Compared to the RTX 3080 Ti, which may solely handle 69 FPS on common, the RTX 4080 produced a mean body price of 99. You can see that the RTX 4080 generated 40–45% extra FPS than the RTX 3080 Ti. The readings present that within the FPS battle of Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti, the winner is RTX 4080.
The working temperature of each the RTX 4080 and RTX 3080 Ti was the identical (81 °C) within the gameplay of God of War.
The RTX 4080 was below as much as 94% of its most load throughout gameplay. In distinction, the RTX 3080 Ti was below 98%. The load on RTX 4080 was about 4% lower than that on RTX 3080 Ti.
Horizon Zero Dawn
Frame charges, GPU Temperature & load in Horizon Zero Dawn
The RTX 4080 may ship a most of 190 frames per second whereas enjoying Horizon Zero Dawn, as in comparison with the RTX 3080 Ti’s highest body price of 135. In addition, the RTX 4080 and RTX 3080 Ti reached the minimal FPS of 37 and 49, respectively.
The RTX 4080 achieved a better FPS restrict. However, the RTX 3080 Ti didn’t attain a decrease FPS on this recreation. The RTX 4080 additionally reached the minimal FPS in Horizon Zero Dawn. At the identical time, the decrease FPS in God of War was attained by RTX 3080 Ti.
The RTX 4080 generated a mean body price of 124 in comparison with the RTX 3080 Ti’s 89 FPS on common. We can see that the RTX 4080 produced about 40% greater frames per second (FPS).
During Horizon Zero Dawn gameplay, the RTX 3080 Ti operated at a temperature of 81 °C. While the working temperature of the RTX 4080 was 79 °C. The temperature distinction isn’t very excessive on this recreation.
The RTX 4080 solely skilled as much as 97% of its most load, whereas the RTX 3080 Ti skilled lower than 99%. The RTX 3080 Ti’s load was only one% lower than its full capability in Horizon Zero Dawn.
Red Dead Redemption 2
Frame charges, GPU Temperature & load in Red Dead Redemption 2
While enjoying Red Dead Redemption 2, the RTX 4080 may yield a most body price of 229, while the RTX 3080 Ti may solely handle a most of 169 FPS. Additionally, the minimal FPS of 49 and 43 had been attained by the RTX 4080 and RTX 3080 Ti, respectively. The RTX 4080 touched a lot elevated FPS limits.
In Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti, the RTX 3080 Ti’s common body price was 74. While the RTX 4080 produced a mean body price of 111. As may be seen, the RTX 4080 generated 50% extra FPS. Thus, RTX 4080 can simply be declared because the winner of the FPS battle.
Similar Comparisons: RTX 4080 Vs RX 6950 XT
The RTX 3080 Ti ran at a temperature of 82 °C, whereas the RTX 4080 ran at a temperature of 81 °C through the playtime of Horizon Zero Dawn. The temperature disparity was virtually negligible all through the gameplay.
While the RTX 3080 Ti skilled about 96% of its most load, the RTX 4080 skilled as much as 95% of its most load.
From temperature and GPU load, we are able to deduce that the RDR 2 was burdening each the graphics card closely and virtually equally.
Watch Dogs Legion
Frame charges, GPU Temperature & load in Watch Dogs Legion
At the noting time in Watch Dogs Legion, the instantaneous FPS dedicated by RTX 4080 was 81, whereas the RTX 3080 Ti was handing over 61 frames in every second.
The RTX 4080 may produce a most body price of 126 whereas enjoying Red Dead Redemption 2. But the RTX 3080 Ti may solely muster a most of 87 FPS. The most FPS attained on this recreation is far lower than RDR 2, indicating Watch Dogs Legion to be extra disturbing.
The RTX 4080 hit the minimal FPS of 34, and 49 frames per second had been turned over by RTX 3080 Ti at its minimal. In Watch Dogs Legion, the RTX 3080 Ti reached fairly decrease FPS ceilings.
The RTX 4080 produced a mean of 89 FPS in distinction to the RTX 3080 Ti’s 68. As noticed, the RTX 4080 produced 21 extra frames per second.
The body time of the RTX 3080 Ti was as giant as 13.8 ms. While the RTX 4080 was delivering one body in 10.4 ms. A decrease body time is at all times crucial for a greater gaming expertise.
During Horizon Zero Dawn gameplay, the RTX 3080 Ti operated at a temperature of 68 °C, and the RTX 4080 ran at a temperature of 68 °C. The temperature distinction is fairly excessive in Watch Dogs Legion, whereas it was hardly noticeable in RDR 2 gameplay.
The RTX 4080 was below solely 72% of its most load. On the opposite hand, the RTX 3080 Ti had a load of 94% of its most worth.
We could infer from temperature and GPU load that the Watch Dogs Legio was taxing the RTX 3080 Ti a lot greater than it loaded RTX 4080.
Second Series – 1440p
Battlefield V, Borderlands 3, Dying Light 2, Elden Ring, Gears оf War 5, Metro Exodus, Prey, Shadow of the Tomb Raider, and Total War: Warhammer had been performed on this collection to get outcomes for the Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti. The benchmarks of this collection had been compiled from PC Tech.
Test PC Specs
The PC used for video games of the second collection had the next specs;
CPU: Intel core i5-13600K
Motherboard: Asus ROG Strix Z790 – F Gaming
RAM: Kingston Fury Renegade RGB DDR5 32GB
SSD: Samsung 980 PRO 2TB PCIe 4.0 NVMe M.2
Case: Cooler Master MCM-H500P-WGNN-S00
Battlefield V
Frame charges of two graphics playing cards in Battlefield V
To begin the comparability of the second collection video games’ efficiency, we discovered Battlefield V to be the most effective decide.
The body price of the Nvidia RTX 4080 was 202 FPS on common, whereas the efficiency of the RTX 3080 Ti was making it ship 190 FPS. So, the RTX 4080 equipped 12 FPS greater than RTX 3080 Ti or ~6.3% higher efficiency.
Borderlands 3
Frame charges of two graphics playing cards in Borderlands 3
The RTX 4080 was managing handy over 110 FPS in Borderlands 3 below the identical circumstances when the RTX 3080 Ti was delivering 109 frames per second. So, in Borderlands 3, the RTX 4080 delivered just one FPS greater than RTX 3080 Ti which isn’t a notable lead.
Dying Light 2
Frame charges of two graphics playing cards in Dying Light 2
In Dying Light 2, the RTX 4080 was turning over 143 frames per second, whereas the RTX 3080 Ti may handle to ship solely 110 FPS. As a consequence, the RTX 4080 performs 33 FPS or 30% higher than the RTX 3080 Ti.
Elden Ring
Frame charges of two graphics playing cards in Elden Ring
Compared to the 93 FPS made by RTX 3080 Ti, the RTX 4080 was capable of ship 120 frames per second in similar circumstances. The RTX 4080 produced 27 extra frames per second in Elden Ring than the RTX 3080 Ti. Therefore, the RTX 4080 produced about ~29% extra FPS than these of the RTX 3080 Ti.
Gears оf War 5
Frame charges of two graphics playing cards in Gears оf War 5
In Gears of War 5, the body price of the RTX 4080 was 142 FPS, in comparison with the RTX 3080 Ti’s 114 FPS. The RTX 4080 remained greater by 28 FPS. As a consequence, the Nvidia GeForce RTX 4080 carried out ~24.5% higher than the RTX 3080 Ti.
Metro Exodus
Frame charges of two graphics playing cards in Metro Exodus
During the interval of Metro Exodus, the RTX 4080 was capable of produce 125 frames per second in distinction to the 93 FPS achieved by the RTX 3080 Ti. Thus, RTX 4080 received the FPS battle of Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti with a lead of 32 frames per second or ~34.4% higher efficiency.
Prey
Frame charges of two graphics playing cards in Prey
The competitors was very powerful in Prey as a result of no graphics card could lead on the opposite on common. Both the Nvidia RTX 4080 and the Nvidia RTX 3080 Ti had been producing the identical common price of 253 frames per second. In some instants, the RTX 4080 tried to guide in FPS, whereas in different instants, the RTX 3080 Ti was main. But there was no common superiority.
Shadow of the Tomb Raider
Frame charges of two graphics playing cards in Shadow of the Tomb Raider
In Shadow of the Tomb Raider, the RTX 4080 turned over 196 frames per second on common which is 40 FPS greater than the body price of 156 FPS rendered by the RTX 3080 Ti. This efficiency distinction equals ~25.6%, and the Nvidia RTX 4080 has served higher.
Total War: Warhammer
Frame charges of two graphics playing cards in Total War: Warhammer
The RTX 4080 produced 252 frames per second throughout Total War: Warhammer gameplay, in comparison with the RTX 3080 Ti’s 185 FPS. Once once more, the RTX 4080 was outperforming the competitors with a 67 FPS benefit or ~36.2% quicker efficiency.
Let us talk about the benchmarks of the third collection now.
Third Series – 4K
In the final collection, we’ve mentioned the efficiency of the Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti in Diablo® II: Resurrected, Minecraft, A Plague Tale: Requiem, Fortnite, Spiderman, and Microsoft Flight Simulator 2020. We collected the benchmarks of those video games from Benchmark Lab.
Test PC Specs
The system used for taking part in video games of the final collection had the specs talked about under;
CPU: Intel i9 13900K
Motherboard: Asus ROG Strix Z690
RAM: Gskill Z Trident DDR 5 – 6200 Mhz 32GB (2 x 16GB)
SSD: SAMSUNG 970 EVO M.2 2280 500 GB
PSU: EVGA Supernova 1000 G5, 80 Plus Gold 1000W
Cooler: AIO – Arctic Freezer 420mm
A Plague Tale: Requiem
Frame charges, GPU Temperature & consumed energy in A Plague Tale Requiem
We chosen A Plague Tale: Requiem to begin the benchmarks of the final collection recreation. This recreation requires a really highly effective GPU. The RTX 4080 was outputting 71 frames per second on the time we took the FPS measurement, whereas the RTX 3080 Ti was placing out 58 FPS.
The 1% low FPS attained by RTX 4080 was 61, and 45 FPS was the 1% low of RTX 3080 Ti. If we discuss concerning the common FPS throughout A Plague Tale: Requiem, the RTX 3080 Ti made a mean of 55 whereas the RTX 4080 made a mean of 74 frames per second. The ~35% improved common FPS and the opposite readings of 1% low, 0.1% low, and instantaneous FPS make RTX 4080 win the FPS battle of Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti.
The load on RTX 4080 was 96% which is 2% lower than the 98% GPU load on RTX 3080 Ti through the gameplay of A Plague Tale: Requiem.The temperature of GPUs is at all times an essential issue. The temperatures of RTX 4080 and RTX 3080 Ti had been the identical on this recreation on the level of 67 °C. This temperature isn’t very a lot excessive to trigger any injury. So, each GPUs had a superb temperature inside secure limits on this recreation.
The energy consumed by GPU performs an essential function in its efficiency. The RTX 4080 consumed a thermal energy of 293 watts, whereas the RTX 3080 Ti had a better TDP of 331 watts through the gameplay.
Diablo® II: Resurrected
Frame charges, GPU Temperature & consumed energy in Diablo® II Resurrected
When we measured FPS within the gameplay of GPU-intensive Diablo® II: Resurrected, the RTX 4080 was producing 184 frames per second whereas the RTX 3080 Ti was producing 144.
RTX 4080 achieved a 1% low body price of 124, whereas RTX 3080 Ti solely managed a 1% low body price of 80.
The RTX 3080 Ti generated a mean body price of 146, whereas the RTX 4080 generated a mean body price of 183 when enjoying Diablo® II: Resurrected. If we evaluate these FPS readings with these of A Plague Tale: Requiem, all forms of FPS are a lot greater in Diablo® II: Resurrected. This reveals that Diablo® II: Resurrected is far much less burdening on GPU than the earlier recreation.
During Diablo® II: Resurrected gaming, the RTX 4080 GPU was below 99% load, and the 98% GPU load was skilled by the RTX 3080 Ti. Both GPUs had been below an enormous load.
In this recreation, the RTX 4080 reached a temperature of 64 °C, whereas the RTX 3080 Ti had a temperature of 69 °C. The RTX 3080 Ti was 5 °C extra oppressive.
During gameplay, the RTX 4080 used 304 watts of thermal energy, whereas the RTX 3080 used 347 watts. The RTX 3080 Ti consumed 43 W extra energy.
Fortnite
Frame charges, GPU Temperature & consumed energy in Fortnite
The RTX 4080 was offering 149 frames per second once we examined FPS within the gameplay of the CPU-intensive Fortnite, whereas the RTX 3080 Ti was producing 112 at the moment.
The 1% low body price for the RTX 4080 was 99, whereas the 1% low body price for the RTX 3080 Ti was solely 87.
In Fortnite, the RTX 3080 Ti produced a mean body price of 113, whereas the RTX 4080 produced a mean body price of 143. Again the RTX 4080 is displaying a greater efficiency by delivering extra FPS.
The RTX 4080 GPU was below 97% load when enjoying Diablo® II: Resurrected, in comparison with the RTX 3080 Ti’s 99% GPU load. The load on RTX 4080 was 2% lesser, however nonetheless, the load on each GPUs was excessive.
The RTX 3080 Ti had a temperature of 69 °C, whereas the RTX 4080 hit 63 °C when enjoying this recreation. So, the RTX 3080 Ti was six levels hotter in Fortnite.
The RTX 4080 used 299 watts of thermal energy when gaming, in comparison with the RTX 3080’s 331 watts. 32 W extra energy was consumed by the RTX 3080 Ti. This distinction has turn into quick in Fortnite, whereas it was 43 watts in Diablo® II: Resurrected.
Microsoft Flight Simulator 2020
Frame charges, GPU Temperature & consumed energy in Microsoft Flight Simulator 2020
In GPU-burdening Microsoft Flight Simulator 2020, the RTX 4080 was producing 129 frames per second, whereas the RTX 3080 Ti was producing solely 77 FPS in the meanwhile.
The RTX 4080 had a 1% low FPS of 99, whereas the RTX 3080 Ti had a low 1% FPS of solely 87.
In this recreation, the RTX 3080 Ti and RTX 4080 delivered common body charges of 124 and 78, respectively. By offering greater FPS, the RTX 4080 is as soon as extra demonstrating superior efficiency in Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti. The distinction in FPS delivered by 2 GPUs has elevated from Fortnite to MSFS 2020.
Also Read: RTX 3080 Vs. 3080 Ti
When enjoying MSFS 2020, the RTX 4080 GPU was below 86% load versus the RTX 3080 Ti’s 96% GPU load. The load on RTX 4080 was 10% lower than it was on the opposite GPU.
Throughout the sport, the RTX 4080 reached 64 °C, and the RTX 3080 Ti reached 71 °C. It was seven levels hotter with the RTX 3080 Ti.
During gameplay, the RTX 4080 consumed 280 watts of thermal energy versus the RTX 3080’s 341 watts. The RTX 3080 Ti used 61 W extra vitality than the RTX 3080. In third collection, it’s the primary time the RTX 4080 consumed that low TDP.
Minecraft
Frame charges, GPU Temperature and consumed energy in Minecraft
The RTX 4080 was yielding 94 frames per second within the CPU-taxing Minecraft, whereas the RTX 3080 Ti was solely capable of generate 66 FPS.
While the RTX 3080 Ti solely had a low 1% FPS of fifty, the RTX 4080 had a low 1% FPS of 84.
The RTX 3080 Ti and RTX 4080 produced 92 and 66 common body charges on this recreation, respectively. Once once more, the RTX 4080 is showcasing better efficiency in Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti by providing greater FPS.
The RTX 4080 GPU was 99% loaded whereas enjoying MSFS 2020, and the RTX 3080 Ti additionally had the identical 99% GPU load. The load on each GPUs was extraordinarily excessive.
The RTX 4080 reached 65 °C, and the RTX 3080 Ti reached 68 °C throughout Minecraft.
The RTX 4080 used 279 watts of thermal energy throughout gameplay versus the RTX 3080’s 312 watts. Compared to the RTX 3080 Ti’s earlier energy consumption, it consumed lesser energy in Minecraft.
Spiderman
Frame charges, GPU Temperature & consumed energy in Spiderman
In Marvel’s Spiderman, the RTX 4080 was yielding 98 frames per second on the time we took efficiency readings, whereas the RTX 3080 Ti may solely present 60 FPS at the moment.
The RTX 4080 had a low 1% FPS of 78, whereas the RTX 3080 Ti merely had a low 1% FPS of 56.
In this recreation, the RTX 3080 Ti and RTX 4080 generated 90 and 61 common body charges, respectively. The RTX 4080 had a lead of about 44-50% in offering higher FPS through the recreation.
The time consumed by RTX 4080 was 13.0 ms to finish every body, whereas the RTX 3080 Ti had a body time of 15.0 ms.
The GPU reminiscence used to play was 10.1 GBs for RTX 4080, whereas the RTX 3080 Ti consumed 10.3 GBs of GPU reminiscence.
While enjoying Spiderman, the RTX 4080 GPU was solely 93% loaded, and the RTX 3080 Ti had an identical GPU load of 98%. The load on RTX 4080 was 6% lower than that in Minecraft.
During the Spiderman, the RTX 4080 reached 62 °C, and the RTX 3080 Ti reached 67 °C. The distinction of 5 levels is illustrious, and the RTX 4080 is cooler.
In gameplay, the RTX 4080 consumed 280 watts of thermal energy versus the RTX 3080’s 310 watts. The distinction in energy consumed by 2 two GPUs has declined from the primary to the final word recreation of the final collection.
Overall Gaming Performance
We will discuss concerning the general gaming efficiency of the Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti when it comes to frames per second and the time of every body.
FPS
When we calculated the imply of common, most, and minimal FPS of every recreation of all collection, the next outcomes had been obtained as indicated by the graph.
FPS delivered by 2 Graphics playing cards
The outcomes are fairly apparent from the graph.
The RTX 4080 turned over about close to about 37% extra frames per second on common as we calculated utilizing the outcomes of all video games’ common FPS.
The most FPS was achieved by RTX 4080 in virtually all of the video games. The common most got here as much as 152 FPS, whereas the typical most FPS of RTX 3080 Ti was 123. It’s a splendid lead of 29 FPS on common most.While speaking concerning the minimal FPS, right here it was reached by RTX 3080 Ti within the majority of video games. The common minimal FPS of RTX 3080 Ti is 50 FPS, whereas that of RTX 4080 69 is about 38 % greater than that delivered by RTX 3080 Ti.
The FPS outcomes are loudly saying that the RTX 4080 is a lot better than the RTX 3080 Ti. And the graph tells us that RTX 4080 has 35-40% improved FPS efficiency over RTX 3080 Ti.
Frame Time
The body time is the reciprocal of FPS. It is the time required to finish one body. For a gamer, a decrease body time is healthier for having fun with a recreation with minimal lag. We have calculated the typical body time consumed by Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti, and it’s proven within the graph under.
Frame time of two GPUs
From calculations, the typical body time consumed by RTX 4080 got here to be 11.5 ms, whereas this body time common was 14.7 ms within the case of RTX 3080 Ti.The RTX 4080 accomplished every body by saving 3.2 ms. That tells the RTX 4080 had an effectivity of ~28% over RTX 3080 Ti when it comes to the body time.
Power Consumption & Thermal Efficiency
As you may have seen in technical variations, the thermal design energy and most working temperature of RTX 3080 Ti are better in Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti. But what concerning the energy consumption and thermal effectivity throughout gameplay?
Power Consumption
The TDPs of RTX 4080 and RTX 3080 Ti are 320 and 350 watts. The common energy consumption of two GPUs calculated by taking the imply of energy consumption by GPUs in all of the video games is proven within the following graph.
The common energy consumed by 2 GPUs
The RTX 3080 Ti consumed about 328 watts of energy on common in all video games, whereas the RTX 4080 consumed much less energy on common at a price of 289 watts.
The better energy consumption results in better electrical energy payments. By selecting RTX 4080 over RTX 3080 Ti it can save you as much as 39.5 watts of energy. It will prevent about 13.65% of electrical energy prices.
Thermal Efficiency
The most temperatures of RTX 4080 and RTX 3080 Ti are 90 °C and 93 °C. However, the upper temperatures may be damaging to your graphics card. The following graph reveals the temperature of two GPUs calculated by taking the imply of particular person temperatures in all video games.
Average temperatures of the 2 graphics playing cards
The common temperature of the RTX 4080 was 76.1 °C in all of the video games, whereas it was 79 °C for RTX 3080 Ti. Even higher efficiency was given by the RTX 4080, however nonetheless, the typical temperature of RTX 3080 Ti is greater. This tells us that the RTX 4080 is thermally extra environment friendly.
The disparities had been famous in some video games just like the temperature of 81 °C was noticed for RTX 4080 in God of War and Red Dead Redemption 2, and a temperature of 67 °C was noticed for RTX 3080 Ti in Spiderman and A Plague Tale Requiem. However, the typical temperature of each GPUs is under their rated most temperatures, which suggests each the graphic playing cards had been working at secure temperatures.
Price and Availability
Now the query comes which GPU presents the most effective worth for the cash? NVIDIA launched the RTX 4080 with a price ticket of 1199$ in November 2022, and the RTX 3080 TI was launched with the identical price ticket of 1199$ in June 2021.
However, the market worth of RTX 3080 TI right now is between 1200$ and 1400$, and it’s simply obtainable on Amazon and different websites. On the opposite hand, the present worth of Nvidia’s newest RTX 4080 graphics card is greater than that. The Gigabyte model RTX 4080 has a mean value of $1550-1600. The Zotac and PNY variants value lesser, and their worth is $1400 to $1500.
The ASUS variants of graphics playing cards are often costly; the ASUS TUF Gaming GeForce RTX® 4080 has a worth of $1699. At the identical time, the most costly one is the ASUS ROG Strix GeForce RTX® 4080 OC Edition, which is priced at as much as $2000. The GeForce RTX 4080 is now obtainable on the market in offline markets and e-commerce web sites like Amazon and eBay and many others.
Which One Should You Go For?
After the profound interpretation of Nvidia RTX 4080 vs. Nvidia RTX 3080 Ti, we famous the next issues. The CUDA®, Tensor, and Ray Tracing cores of RTX 3080 Ti are greater than these of RTX 4080. A better variety of cores will help in higher processing. However, the expertise of chip design of RTX 4080 is the most recent and improved.
The RTX 4080 comes with the most recent Ada Lovelace structure, and the RTX 3080 Ti has the Ampere structure. The AD-103 chip of RTX 4080 is manufactured in a 4 nm fabrication course of, whereas the GA-102 of RTX 3080 Ti is simulated in an 8 nm manufacturing course of.There are far more transistors with smaller die sizes in RTX 4080 to enhance the GPU efficiency to sensible limits and make the scale of the graphics card smaller.
Both the bottom and enhance clock speeds of RTX 4080 are a lot better than RTX 3080 Ti. Thus, the brand new RTX 4080 can carry out duties with better velocity saving quite a lot of valuable time.
The TDP of RTX 4080 is lower than that of RTX 3080 Ti, so the electrical energy may be saved by going for RTX 4080, which is able to cut back your electrical energy value.
The most temperature of the RTX 3080 Ti is 3 °C greater than that of the RTX 4080. So, RTX 3080 Ti can function at a better temperature.
The main advantage of RTX 4080 is that it has 16 GB RAM whereas the RAM of RTX 3080 Ti is 12 GB. Large RAM helps in higher gaming. Also, the reminiscence velocity and bandwidth of the RTX 4080 are a lot greater than these of the RTX 3080 Ti.
You have already seen the gaming efficiency of each graphics playing cards. So, to conclude, we might advocate that it’s best to go for the Nvidia GeForce RTX 4080 as a substitute of the RTX 3080 Ti due to its a lot better efficiency and improved expertise. However, if RTX 4080 isn’t obtainable to you or the worth available in the market turns into very a lot excessive, you may also go for RTX 3080 Ti as its efficiency can also be good in gaming and different purposes if not in contrast with the RTX 4080.
Common Questions AnsweredWhat is the RAM of Nvidia RTX 4080, 12 GB or 16 GB?The RAM of the Nvidia RTX 4080 is 16 GB with 256-Bit interface width, a reminiscence velocity of twenty-two.4 GB/s, and a bandwidth of 912 GB/s. The 12 GB variant of RTX 4080 was declared to not launch. Can I overclock RTX 3080 Ti?Yes, the RTX 3080 Ti is unlocked for overclocking.What is the structure of RTX 4080, and which chip is used for it? The RTX 4080 has the present Ada Lovelace structure. And the chip used for it’s AD-103 which is simulated at TSMC in a 4 nm fabrication course of.Which graphics card is healthier for gaming, RTX 4080 or RTX 3080 Ti? The RTX 4080 is healthier among the many two graphics playing cards. Its efficiency is 35-40% higher than the RTX 3080 Ti.
Was our article useful? 👨💻
👍Yes
👎No
Thank you! Please share your constructive suggestions. 🔋
How may we enhance this put up? Please Help us. 😔
Submit
https://news.google.com/__i/rss/rd/articles/CBMiMGh0dHBzOi8vdGVjaDRnYW1lcnMuY29tL3J0eC00MDgwLXZzLXJ0eC0zMDgwLXRpL9IBAA?oc=5
